Custom CAD, drawn by the person who builds the parts
Send us what you need modelled — a part, an intake manifold, a flange, a fixture, or something you only have as a physical piece — and G1Pro will draw it in SOLIDWORKS and hand you production-ready files.
What we deliver
- Native SOLIDWORKS parts and assemblies, plus STEP for any CAD system
- DXF flat patterns for laser, plasma and waterjet cutting
- STL for 3D or metal printing
- PDF drawings with the dimensions your shop needs
How it works
- Tell us the job. Message us or place the design deposit with your notes, photos, sketches or existing files.
- We agree the scope. We confirm what will be drawn, the files you will get and the total before any further charge.
- We design with you. You review previews and we revise until it is right.
- You get your files. Delivered digitally — nothing ships.
The deposit is credited in full to your project total. Reverse engineering from a part is supported where the part can be measured or 3D scanned; we will tell you up front if a feature cannot be captured accurately.
Drawn by James Goertz, G1Pro — building intake manifolds and fabrication tooling since 2009.
Pricing and terms
- Design deposit — $99 (credited to your project)
- Simple part or flat plate (DXF + PDF) — $149
- Standard part (STEP + SOLIDWORKS + PDF drawing) — $295
- Reverse engineering from your 3D scan (per part) — $395
- Fixture or assembly (up to 5 parts) — $595
- Intake / turbo manifold or collector design — $1,250
- Engineering time block — 10 hours — $950
- Engineering time block — 40 hours (priority) — $3,400
Scope is confirmed in writing before work starts.
If a job is larger than its package, we quote the difference before continuing; nothing extra is charged without your agreement.
Two revision rounds are included.
You review previews and approve the design before final files are released.
Final files are delivered digitally after payment in full.
All sales are final.
Larger programs and multi-part projects can be scoped as a fixed-price program on request.
Not sure which package fits? Choose the deposit or the free quote and send your photos, sketches or files.
