A physical G1Pro mandrel-elbow cutting fixture with an angle gauge. The fixture halves surround the elbow, while the gauge provides a reference for planning your cuts.
Choose your fixture
- Select the tube outside diameter and centerline-radius option that matches your elbow.
- This listing is for a printed physical tool, not an STL download.
- The interactive example shows a 3.50-inch outside diameter and a 4-inch centerline radius.
For a configuration not listed, contact G1Pro with your tube dimensions and bend radius before ordering.
Material and print specification
Printed in-house in Inland PETG-CF: 2.5 mm walls, 2.5 mm top and bottom, 20% cubic infill, support-free printing.
